首頁 / 產品與服務 / CMP不銹鋼非鎧防爆格蘭（A2F系列）

產品與服務

CMP不銹鋼非鎧防爆格蘭（A2F系列）

價格
詢價
產品類別
化工/化工設備配件
品牌
英國CMP
規格型號
A2F系列
庫存
500
生產商
英國CMP
產品介紹
規格參數
免責聲明

CMP不銹鋼非鎧防爆格蘭（A2F-SS316L系列）CMP A2F Cable Gland

Hazardous Area Cable Glands-ATEX IECEX，Exe，Exd Group II

CMP防爆格蘭代理商：上海頤品自動化科技有限公司

關鍵詞：CMP防爆格蘭，CMP防爆變徑，CMP防爆堵頭，CMP防爆呼吸閥

CMP防爆格蘭等產品規格書及相關證書-請咨詢上海頤品自動化科技有限公司

A2F Cable Gland，explosive atmosphere single seal globally approved gland

Globally Approved, Explosive Atmosphere Cable Gland

? Displacement type flameproof seal

? Deluge protected

? -60°C to +130°C (standard), -20°C to 200°C (ThermEx option )

? Globally marked, IECEx, ATEX & CSA

? Class I Zone 1, Class I Division 2 BCD (Canada Only)

For all types of Unarmoured & Braid Armour Cables

Design Specification

6121:Part 1:1989, IEC 62444, EN 62444

Mechanical Classifications*

Impact = Level 8, Retention = Class B

Enclosure Protection

IK10 to IEC 62262 (20 joules) Brass & Stainless Steel only

ATEX Certificate

SIRA13ATEX1068X, SIRA13ATEX4074X

Code of Protection

II 2G, II 1D Ex d IIC Gb, Ex e IIC Gb, Ex ta IIIC Da
II 3G Ex nR IIC Gc I M2 Ex d I Mb, Ex e I Mb

Compliance Standards

EN 60079-0,1,7,15,31

IECEx Certificate

IECEx SIR 13.0023X, IECEx SIM 14.0006

Code of Protection

Ex d IIC Gb, Ex e IIC Gb, Ex nR IIC Gc, Ex ta IIIC Da, Ex d I Mb, Ex e I Mb

Compliance Standards

IEC 60079-0,1,7,15,31

CSA Certificate

1211841

Code of Protection

Class I, Div 2 Groups B, C, D; Class II, Div 2 Groups E, F, G; Class III, Div 2; Type 4X: Oil Resistant II: Ex d IIC, Ex e II, Ex nR II

Compliance Standards

C22.2 No 0,0.4, 94, 174, CAN/CSA-E60079-0,1,7,15

EAC Certificate

C-GB.AA87.B.00487

KCC Certificate

13_GA4BO_0748X, 13_GA4BO_0749X, 13_GA4BO_0750X, 14_GA4BO_0251X

NEPSI Certificate

GYJ13.1140X , GYJ13.1282X

INMETRO Certificate

TüV 12.0619X

CCOE / PESO (India) Certificate

P333688

RETIE Certificate

03866

Marine Approvals

LRS: 01/00172 (E3), DNV: TAE00000Y, ABS: 14-LD234401A-4-PDA, BV: 43180/A1BV

Ingress Protection Rating **

IP66, IP67 & IP68

Deluge Protection Compliance

DTS01 : 91

Cable Gland Material

Brass, Electroless Nickel Plated Brass, Stainless Steel, Aluminium

Seal Material

CMP SOLO LSF Halogen Free Thermoset Elastomer

Cable Type

Unarmoured & Braided when terminated inside enclosure

Sealing Technique

CMP Unique Displacement Seal Concept

Sealing Area(s)

Cable Outer Sheath

Optional Accessories

Locknuts, Earth Tags, Serrated Washers, Entry Thread Seals, Shrouds,Ingress Discs

Optional Installation Tools

Spanners, Armour Former Tool

PRODUCT SELECTION TABLE

Cable Gland SizeAvailable Entry Threads ＇C＇ (Alternate Metric Thread Lengths Available)Overall
Cable
Diameter
＇A＇		Across
Flats
＇D＇		Across
Corners
＇D＇		Protrusion
Length ＇F＇		Combined Ordering Reference
(*Brass Metric)		ShroudCable
Gland
Weight
(kgs)
StandardOption
MetricThread Length (Metric) ＇E＇NPTThread Length
(NPT) ＇E＇		NPTMinMaxMaxMaxSizeTypeOrdering
Suffix
16M1615.0---3.28.724.026.429.916A2F1RAPVC040.06
20S16M2015.0?"19.9?"3.28.724.026.426.020S16A2F1RAPVC040.07
20SM2015.0?"19.9?"6.111.724.026.426.020SA2F1RAPVC040.06
20M2015.0?"19.9?"6.514.027.029.727.720A2F1RAPVC050.07
25M2515.0?"20.21"11.120.036.039.635.525A2F1RAPVC090.13
32M3215.01"25.01 ?"17.026.341.045.135.132A2F1RAPVC100.15
40M4015.01 ?"25.61 ?"23.532.250.055.035.140A2F1RAPVC130.20
50SM5015.01 ?"26.12"31.038.255.060.533.050SA2F1RAPVC150.26
50M5015.02"26.92 ?"35.644.060.066.037.350A2F1RAPVC180.27
63SM6315.02"26.92 ?"41.549.970.577.633.563SA2F1RAPVC210.43
63M6315.02 ?"39.93"47.255.975.082.536.263A2F1RAPVC230.40
75SM7515.02 ?"39.93"54.061.984.092.434.175SA2F1RAPVC240.52
75M7515.03"41.53 ?"61.167.984.092.440.975A2F1RAPVC240.50
90M9024.03 ?"42.84"66.679.9108.0118.860.390A2F1RAPVC311.60
100M10024.03 ?"42.84"76.091.0123.0135.357.2100A2F1RA-1.78
115M11524.04"44.05"86.097.9133.4146.767.3115A2F1RA-2.67
130M13024.05"46.8-97.0114.9152.4167.674.7130A2F1RA-3.80
Dimensions are displayed in millimetres unless otherwise stated

TECHNICAL ILLUSTRATION

CMP防爆格蘭（A2F系列）CMP A2F Cable Gland

Hazardous Area Cable Glands-ATEX IECEX，Exe，Exd Group II

CMP防爆格蘭代理商：上海頤品自動化科技有限公司

關鍵詞：CMP防爆格蘭，CMP防爆變徑，CMP防爆堵頭，CMP防爆呼吸閥

CMP防爆格蘭等產品規格書及相關證書-請咨詢上海頤品自動化科技有限公司

產品名稱：CMP不銹鋼非鎧防爆格蘭（A2F系列）

產品類別：化工/化工設備配件
